AL6-12VDC-C-S40

Features: Up to 40A switching capability; 1 Form A & 1 Form C contact arrangement; Plastic Bracket & Metal Bracket Available; Ambient temperature range: -40℃ to 85℃; Environmental friendly product (RoHS compliant); Available for PC board mounting & direct insert mounting; Application: Rear Windows Defogger; Battery Disconnection Device; Air-Conditioning System; Power Distribution; Fog Lamp & Headlight Control; Fuel Pump Control; ABS; Traction Control system; Cooling Fan Control; Heating Control; Power Supply Management System, etc;

Share to:
Consultation Related articles

Model: AL

Product Detail
Coil Voltage: 12~24VDC
Contact Arrangement: 1 Form A, 1 Form C
Contact Rating:
1A: 40A 14VDC
1C: NO: 40A 14VDC
NC: 30A 14VDC
Max. Switching Power: 560W
Max. Switching Current: 40A
Min. Contact Load: 1A 6VDC
Coil Power Consumption: 1.6W~1.8W
Standard Type / Plastic Bracket / Metal Bracket available
Paralleled Component: with diode / with resistor
Standard flux tight / sealed type
Weight: Approx. 28g
Dimensions (mm)
27.4 × 28.4 × 25.0
