AJ-12VDC-C12-S35

Features: 1 Form A & 1 Form C contact arrangement; Ambient temperature range: -40℃ to 125℃; 2.8mm QC terminals; Environmental friendly product (RoHS compliant); Application: Headlight Control; Fuel Pump Control; Horn control; A/C Compressor Clutch,etc.;

Share to:
Consultation Related articles

Model: AJ

Product Detail
Coil Voltage: 12VDC~24VDC Automotive Relay
Contact Arrangement: 1 Form A, 1 Form C
Single Contact: SPST, SPDT
Max. Switching Current: 35A
Contact Rating:
1A: 35A 14VDC
1C: NO: 35A 14VDC
NC: 20A 14VDC
Max. Switching Power: 490W
Max. Switching Current: 35A
Paralleled Component: Resistor & Diode available
Terminal Type: QC, Plug in
Weight: Approx. 19.6g
Dimensions (mm)
22.5 × 15 × 25.2
