Subminiature Signal Relay; Features: 3Kv dielectric strength (between coil and contact); Surge withstand voltage up to 6000VAC; Min. creepage is 2.5mm (between coil and contact); Min. clearance is 2.0mm (between coil and contact); Bifurcated contacts with contact gap ≧1.5mm; Available in DIP & SMT type; Available in single side stable & latching type; Environmental friendly product (RoHS compliant); Dimensions: 15.0 x 7.5 x 9.2 mm; Application: Telecommunication Equipment / Security Alarm Systems / Measuring; Instruments / Medical Monitoring Equipment / Audio Visual Equipment / Flight; Simulator / Sensor Control, etc.
