Features Special contact struction; Incandescent lamp load: 3000W 230VAC; 5kV dielectric strength (between coil and contacts); Creepage distance: 10mm; Low height: 15.7 mm; Meeting reinforce insulation; Plastic sealed and flux proofed types available; UL insulation system：Class F available; Environmental friendly product (RoHS compliant); Dimensions: 29.0 x 12.7 x 15.7 mm; Application: Intelligent Building / Intelligent Office / Intelligent Home Control / Lighting Control, etc.
| Product Detail |
|
|---|---|
| Dimensions (mm) |
|
>>>>
