Location：Home > Product > GENERAL POWER RELAY >

< >

GEL-12D-A

Features: 8A switching capability; Creepage distance: 6mm (coil & contacts); 1 Form A and 1 Form C configurations; High sensitivity 200mW; 5KV dielectric between coil to contacts; UL insulation system: Class F available; Environmental friendly product (RoHS compliant); Dimensions: 20.0 x 10.0 x 10.6 mm; Application: Home appliances; Intelligent home; Industrial and office automation control; Alarm control panel; Frequency converter, etc;

Consultation Related articles

Model: GEL

Product Detail	Coil Voltage Form: DC relay Terminal Type: PCB Coil Voltage: 3~48VDC Contact Arrangement: 1 Form A, 1 Form C Contact Version: Single contact Contact Rating: 1A: 6A 250VAC / 30VDC, 8A 250VAC / 30VDC, 10A 120VAC 1C: NO: 6A 250VAC / 30VDC, 8A 250VAC / 30VDC, 10A 120VAC; NC: 5A 250VAC / 30VDC Max. Switching Power: 1250VA / 180W Max. Switching Voltage: 277VAC / 30VDC Max. Switching Current: 8A Weight: Approx. 4.6g
Dimensions (mm)	20.0 × 10.0 × 10.6

Product Detail

Coil Voltage Form: DC relay

Terminal Type: PCB

Coil Voltage: 3~48VDC

Contact Arrangement: 1 Form A, 1 Form C

Contact Version: Single contact

Contact Rating:
1A: 6A 250VAC / 30VDC, 8A 250VAC / 30VDC, 10A 120VAC
1C: NO: 6A 250VAC / 30VDC, 8A 250VAC / 30VDC, 10A 120VAC;
NC: 5A 250VAC / 30VDC

Max. Switching Power: 1250VA / 180W

Max. Switching Voltage: 277VAC / 30VDC

Max. Switching Current: 8A

Weight: Approx. 4.6g

Dimensions (mm)
